ITEMS |
UNIT |
DMK-CM16 |
DMK-CM24 |
DMK-CM28 |
DMK-CM36 |
DMK-CM48 |
Raw material |
|
PP/HDPE/LDPE/PTE |
PP/HDPE/LDPE/PTE |
PP/HDPE/LDPE/PTE |
PP/HDPE/LDPE/PTE |
PP/HDPE/LDPE/PTE |
Max capacity |
pcs/hr |
9000-16000 |
17000-25000 |
19000-28000 |
22000-36000 |
33000-52000 |
3025 capacity |
pcs/hr |
16000 |
25000 |
28000 |
36000 |
52000 |
38mm capacity |
pcs/hr |
9000 |
17000 |
19000 |
22000 |
33000 |
Diameter of cap |
mm |
22-42 |
22-42 |
22-42 |
22-42 |
22-42 |
Height of cap |
mm |
10-25 |
10-25 |
10-25 |
10-25 |
10-25 |
Number of cavity |
PCS |
16 |
24 |
28 |
36 |
48 |
Actual power consumption |
KW |
16-20 |
28-33 |
32-35 |
32-42 |
50-60 |
Operating pressure |
Mpa |
0.8 |
0.8 |
0.8 |
0.8 |
0.8 |
Pressure consuming |
M3/hr |
2 |
2 |
2 |
2 |
2 |
Power supply |
V/HZ |
380V/50HZ |
380V/50HZ |
380V/50HZ |
380V/50HZ |
380V/50HZ |
Machine weight |
TON |
4.5 |
6.3 |
6.5 |
8 |
11.5 |
Dimension |
mm |
4300*1750*2600 |
4800*2180*2600 |
4800*2180*2600 |
5300*2180*2600 |
6100*2180*2600 |
Installation power |
KW |
40 |
55 |
55 |
95 |
75 |
|
|
|
|
|
|
|
* Demark se reserva el derecho de realizar cambios en los productos y las especificaciones están sujetas a cambios sin previo aviso.
