Unit |
SBL2 |
SBL3 |
SBL4 |
SBL6 |
| Productivity(5L) |
Bph |
900-1000 |
2300-2500 |
3000-3600 |
4600-5100 |
| Mould Plate Stroke |
mm |
320 |
220 |
220 |
210 |
| Stretching Stroke |
mm |
500 |
350 |
350 |
350 |
| Bottom Die Trip |
mm |
50 |
30~50 |
30~50 |
30~50 |
| Number Of Cavity |
pcs |
2 |
3 |
4 |
6 |
| Cavity Spacing |
mm |
320 |
190.5 |
190.5 |
203.2 |
| Max Volume Of Continer |
L |
20 |
5 |
5 |
5 |
| Max Neck Diameter |
mm |
75 |
48 |
48 |
55 |
| Max Continer Diameter |
mm |
290 |
175 |
175 |
180 |
| Max Continer Height |
mm |
490 |
350 |
350 |
330 |
| Max Height Of Bottle Preform |
mm |
210 |
180 |
180 |
180 |
| Heating Box Number |
pcs |
6 |
6 |
8 |
8 |
| Heating Box Lamp Number |
pcs |
15 |
12 |
12 |
9 |
| Max Heating Power |
KW |
100 |
117 |
156 |
180 |
| Installed The Total Power |
KW |
125 |
150 |
180 |
202 |
| Actual Power Consumption |
KW |
50-80 |
60-80 |
70-90 |
110-140KW |
| Voltage/Frequency(50hz) |
V |
380(50Hz) |
380(50Hz) |
380(50Hz) |
380(50Hz) |
| Operataing Pressure |
Kg/cm3 |
7~10 |
7~10 |
7~10 |
7~10 |
| Low Pressure Consuming |
L/min |
2000 |
2000 |
3000 |
3000 |
| Blowing Pressure |
Kg/cm3 |
25~40 |
25~40 |
25~40 |
25~40 |
| High Pressure Consuming |
L/min |
16000 |
12000 |
15000 |
27000 |
| Cold Water Machine Pressure |
Kg/cm3 |
3~5 |
3~5 |
3~5 |
3~5 |
| Temperature Range |
℃ |
8~10 |
8~10 |
8~10 |
8~10 |
| Consumption |
Kcal/hr |
26040 |
40000 |
45000 |
50000 |
| Machine Dimension |
M |
6.7X2.9X3 |
6.5X2.5X3.2 |
7.6X2.6X3.3 |
9.5mX2.6mX3.9m |
| Machine Weight |
Ton |
14 |
9 |
12 |
20 |
* Demark se reserva el derecho de realizar cambios en los productos y las especificaciones están sujetas a cambios sin previo aviso.
